Detail K2 MMT5X7-DUG Utility Trailer
5ft x 7ft Multi Purpose Utility Trailer Kits - Powder coated with Drive Up Gate - MMT5X7G
The DK2 MMT5X7 with Drive Up Gate is a single axle multi-utility trailer and one of the most versatile trailers on the market. Sitting on a solid square tube cambered axle with 12 Inch radial tires, and a load capacity of 1,639 Lbs. When the front and back load-bearing gates are down, the trailer bed extends to nearly 11.58 ft. Another great feature is the tilt/dump capability that makes it easy to load or unload heavy items. Fabricated from 100% steel, all of the components are reinforced, adjustable, removable and / or interchangeable.Ā Trailer wheel Jack not included.
Key Features
- Fully welded heavy-duty powder-coated tubular steel frame, Removable 100% steel corrugated floor and solid side and front panels/rails
- Load capacity: 1639 lb., Floor height: 20-Inch, Box dimension 52" x 88" x 8", Solid Steel Drive Up Gate
- Solid square tube cambered axle, V shape drawbar-tongue for added strength & support, Axle Length: 68.11"; Hub Size: 1"-Bearing #30205; Bearing Seal #305010; 4 Bearings & 2 Seals; GVWR: 2,090 Lbs
- Entire Trailer Galvanized, Radial tires: 5.3" x 12" (6 ply nylon cord), Bolt pattern: 5 x 4.5-Inch
- Quick release lock-pin, Load-bearing front and back drop gate, 2 position dump bed, Hitch height: 16-Inch
- Trailer fully pre-wired with Plug and Play 4-Inch, flat connectors to reduCE time of assembly, Removable two gates can be extended
- Extended dimensions (L x W): 11.58 ft. x 4.4 ft, Bed dimensions (L x W): 7.1 ft. x 4.4 ft., Overall length: 7 ft.(with front and back gates up)
- Includes: 2 inch coupler with safety chains, LED Lights, 3 Leaf spring, Assembly required, Weight: 451 Lbs
- Includes all necessary paperwork for registering with local DMV, 5.3" x 12' D.O.T. tires (2)
Key downloads
See this in action
Disclaimer: Product features vary over time so be sure to read the entire product description to verify the features of this product and what it includes at this time.
